    Corrugated Carton Pizza Box Printing Die Cutting Machine 120pcs/min

    Ask Lasest Price
    Brand Name : Da hua
    Model Number : GYKM series
    Certification : CE,ISO,SGS
    Price : USD 30000 - USD90000 per set
    Payment Terms : T/T, L/C, Western Union, D/P, MoneyGram, D/A
    Supply Ability : 30 sets per month
    Delivery Time : 35-50 days
    • Product Details
    • Company Profile

    Corrugated Carton Pizza Box Printing Die Cutting Machine 120pcs/min

    corrugated carton pizza box printing die cutting machine


    1 Whole machine electric parts was choice the domestic famous brand, good quality and steady.


    2 Complete machine baffle and important parts used the temper for decrease the metal internal force; and that parts are made by high precision processing center and grinded by digit controlled grinder.


    3 All the transmission axles and rollers are made by high-quality steel, and processed through temper and dynamic balance ; plated with rigid chrome and grinded surface.


    4 All the transmission gears was used the 45# alloy steel, which is grinded after heat-treatment, and it was made by rubbing, it still maintains the high topping precision.


    5 The whole machine undergoes the spray lubrication, intuitionist show setting, setting the double oil pipe balance system.


    Paper-feeding: Chain, paper pushing feeding.


    Open and closing of the unit adopts electrical walking and pneumatic locking (with overload protection function).

    Paper-feeding roller: The upper axle adopts ginning paper-feeding wheel while the lower axle adopts steel ginning roller. The surface hard chromium-plating guarantees the smooth feeding of the paperboard and does not damage the corrugated cap.

    Printing roller: You can adopt the advanced, convenient and practical hanging plate with hooked slots (Optional). Loading and unloading the plate can be independently controlled by the pedal switch. The phase adjusting adopts non-stop-working, 360o electrical and numerical adjustment. Input the data as per the error. Automatically adjust.


    Parameter

    automatic carton making machine920122414261628
    Max speed (pcs/min)300250180160
    Feeding precision(mm)±1
    Min sheet size(mm)300*600420*600450*600450*600
    Max sheet size(mm)860*21001150*25001350*27001500*2900
    Skip sheet size|(mm)1200*21001500*25001800*27002000*2900
    Max printing area(mm)900*20001200*24001400*26001600*2800
    Printing precision(mm)±0.5
    Plate thickness(mm)7.2

    positive knife

    Min slotting distance

    negative knife

    130*130*130*130140*140*140*140150*150*150*150
    230*65*230*65230*70*230*70240*75*240*75
    Max slot depth230300360400
    increase the blade, increase the slot depth
    Slotting precision(mm)±1
    Max die cutting size(mm)2000240026002800
    Die cutting precision(mm)±1
