Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min

    Buy cheap Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min from wholesalers

    Buy cheap Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min from wholesalers
    • Buy cheap Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min from wholesalers

    Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min

    Ask Lasest Price
    Brand Name : Dahua
    Model Number : BZJ-1300L,BZJ-1450L
    Certification : CE,ISO,SGS
    Price : usd30000 -40000 per set
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 30 sets per month
    Delivery Time : 25-40 days
    • Product Details
    • Company Profile

    Corrugated Box Color Box Full Automatic Flute Laminating Machine 100pcs/min

    Corrugated Box Color Box Full Automatic Flute Laminating Machine

    1. Adopt unique pressing spring front gauge registration design compliant with PLC control system,it makes machine run at high lamination precision and low rate of breaking down.
    2. Use frequency converter for speed regulation,PLC central,simulation to digit program system.
    3. Double servo motors are used to control bottom sheets to get to the front gauge timely and accurately.Thus the machine accuracy is ensures even in operation adjusting conditions.
    4. Balance-tested rollers,tight assembling technique,plus timing belts driving mechanic system makes the machine run at low noice with high precison.
    5. The machine adopts automatic glue supply and recyclable glue circulating system.
    6. Self-developed high-strength feeder compliant with high configuration electric system.
    7. The electric parts used are all world wide available brand or well-known Chinese brand.
    8. All material are inspected according to ISO-9001 standard and the key parts such as bearing are imported ones.
    9. The face sheet for this machine can be 150-450GMS.The bottom sheet can be A,B,C,D,E,F flute corrugated sheet as well as 3 ply or 5 ply board with the maximum thickness not more than 8mm.

    Technical parameter

    Model

    Items

    unitBZJ-1300LBZJ-1450L
    Max. paper size(WxL)mm1300x13001450x1300
    Min. paper size(WxL)mm350x350350x350
    Laminating precisionmm≤±1.5≤±1.5
    Speedpc/min100100
    Total powerkw1313
    Overall dimensionmm12000x2250x265512000x2400x2655

    Semi automatic flute laminator machine for option.

    Semi automatic type technical parameters:


    Model

    HL-1300A-I


    HL-1500A-IHL-1600A-I
    Max size of cover face1300mm×1250mm1500mm×1250mm1600mm×1250mm
    Mix size of cover face360mm×360mm360mm×360mm360mm×360mm
    Economic speed0-100pcs/min0-100pcs/min0-100pcs/min
    Lamindin precision±1±1±1
    Power6KW6.5KW6.5KW
    Size8.8M×1.95m×1.7m8.8M×2.15m×1.7m8.8M×2.25m×1.7m
    WeightAbout 3tAbout 3.5tAbout 3.5t
